2 layers FPC PCB-FPC Cables Module+Adhesive tape

Material: PI, PET or Equivalents

Finish: ENIG, OSP, Immersion Silver, Immersion Tin, Glod Plating, Gold Plating+ENIG, Gold Plating+OSP

Copper Foil: 1/3OZ-6OZ

Polyimide: 0.5mil, 1mil, 2mil, Specifications based on design. (black, white, Amber)

Min. Line/Spacing: 0.05mm/0.05mm

Impedance Tolerance (if applicable): ±10％

Min. Drilling hole: 0.10mm

PTH tolerance: +/- 0.075mm

Silkscreen: White or Black (TBD)

Outline tolerance: +/-0.10MM or 0.05MM

Shipping: by Array or By Individual Pieces

Online Consulting Download PDF

Product Detail

Design Support

HMLV, Quick-Turn Service

Shipping Solutions

These products are used for FPC connector cable, FPC cable layout, LCM/LCD display cable layout, mobile phone cable layout, TFT card etc.

As a professional flexible PCB manufacturer, we can manufacture your flexible PCB for you. Both protoype and mass production, based on high quality and high reliability of quality and competitive price. If you need to purchase FPC flexible PCB, please feel free to contact us.

According to IPC-6013, Board type including:

Type 1 Single-Sided Flexible Printed Boards.(1 layer FPC PCB)

Type 2 Double-Sided Flexible Printed Boards.(2 layers FPC PCB)

Type 3 Multilayer Flexible Printed Boards.(4 layers and above FPC PCB)

Type 4 Multilayer rigid and flexible material combinations containing three or more conductive layers with PTHs. (Rigid-Flex PCB with multiple layers)

Type 5 Flexible or rigid-flex printed boards containing two or more conductive layers without PTHs. (Rigid-Flex PCB with multiple layers)

At earlier stage, technical support is important for you to proceed the designs, from line width/spacing to stackup (material selection), especially for impedance control value calculation, Please feel free to contact us for any questions.

Greathome recommend that all new projects should have prototypes confirmation before mass production. Prototype is important for technology review, meanwhile, it would be helpful to get the most competitive price for mass production and resonable lead time.

From Quick-Turn prototype to series production, we are doing our best to meet customers’ lead time requirement.

Following your shipping instruction if there is any. if not, we will recommend the most competitive shipping terms according to our experience.

Such as FedEx, UPS, DHL or professional international Freight forwarder etc.

Greathome is experienced with all the paperwork for customs. With more than 13 years of experience in exporting to more than 1000 customers around the world, we will deliver your goods to you safely and quickly with our expertise and experience. (Warehouse/factory/company)
